Why is my HWH leveling system Jack not retracting?

All the information you need can be found on their web site. My first guess would be the corresponding solenoid is stuck in a slightly open position, or not closing all the way. However, the first thing I would do is with the jacks down is to spray the seal on the jacks with WD-40.

Why does one HWH Jack not go down?

That bolt is for the pressure switch on AUTO level HWH systems. NOT used and is just a PLUG. I have NEVER seen a Jack (HWH) NOT fully extend for any type defect. There is 3000 psi of pressure on the system. AT the solenoid for THAT stuck jack, crack the line nut open and see if the jack retracts (fluid will squirt out).

What happens when all 4 HWH Jacks extend?

If all 4 jacks extend (including the one that did not extend before), then either that jack solenoid is bad or there is NO 12 volt power to THAT solenoid when power is applied. When doing this test, all jacks will extend as long as the pump is running, when the pump syops all 4 jacks will then retract 4.

How much does it cost to replace leveling jacks?

The rear leveling jacks go down but do not fully retract. I had the coach in for service recently and the dealer said the jacks needed to be replaced. Estimated cost ~$1,000. Has anyone replaced them on their own?

What should I use to level my HWH Jacks?

I extended the jacks, cleaned the rods (shiny, movable part of jack) with WD40 and then they fully retracted. It seemed to work for me. I had some problems with my HWH jacks at one time. The service guy suggested that I spray the rods with silicone instead of WD40 or any lubricant that can attract dirt. I’ve been doing that and no problems.

How to remove solenoid from HWH leveling system?

So I had to unbolt the mounting brackets for the strut, carefully lower the strut and unwind it 3 full turns. Then I continued to unwind the strut another 3 turns to give me more removal turns back up at the solenoid. I then bolted the strut in enough to hold it and finished removing the solenoid.

How to check the fluid reservoir for HWH leveling?

Proper oil level should appear in the range between the two scribed lines on the dipstick. Add HWH Specialty hydraulic oil or Dexron-style automatic transmission fluid to the reservoir if necessary.

Why is my HWH 200 not leveling properly?

As in all high-pressure hydraulic systems, maintaining the proper oil level in the reservoir of the HWH 200 prevents air from entering the system. Failure of the jacks to fully extend is the primary symptom of insufficient hydraulic oil and air in the system. Retract all four jacks fully.

Which is HWH leveling system is better?

BI-AXIS leveling is the process of using two jacks at a time to level the coach from side-to-side (if necessary) and from front-to-rear. HWH air leveling also utilizes BI-AXIS logic. 16. Which HWH leveling system is better?

What do you need to know about HWH hydraulic systems?

HWH® SERVICE MANUAL DESCRIPTION Leveling Method (Air or Jacks) HWH Slide-Out Status Air Dump Feature Service Manual (Click to Open) HWH® Hand Pump Hydraulic Systems (All Models) Priming the Hand Pump Power-Retract and Spring-Retract Jacks. JACKS MP44.0009 Hand-Pump Hydraulic Systems C:\TEMP0_srvc.xls | Revised: 05APR19 | Page 2 of 9

What to do if your Jacks wont retract?

Now the jacks should retract with the use of the “STORE” function on the touch panel. IF THE JACKS WILL STILL NOT RETRACT 1. Turn the system off and make sure all solenoid valves are closed. 2. Remove the “U” shaped tube from the shuttle valve (9/16″ wrench) and remove the shuttle valve. A 7/8″ wrench is needed. 3.

What kind of leveling system does my Winnebago have?

I have an HWH touch panel-controlled leveling system, series 310 on my 2002 Winnebago Adventurer. I don’t use the RV very much these days usually only putting about 1000 miles per year on it.

What to do if solenoid jacks do not retract?

IF THE JACKS WILL STILL NOT RETRACT 1. Turn the system off and make sure all solenoid valves are closed. 2. Remove the “U” shaped tube from the shuttle valve (9/16″ wrench) and remove the shuttle valve. A 7/8″ wrench is needed. 3. There should be a small pin protruding from the bottom of the shuttle valve.

How are the leveling jacks and slide out issues?

When I turn the hydraulic system on I can clearly hear the electric over hydraulic systems engaging, when I set the system to auto level the coach I see all four jacks extend until they each contact the ground however there is insufficient force to lift the coach or to complete a thorough leveling cycle.

Why is my hydraulic elevator not leveling up?

Hydraulic elevators mainly use the system of switches. They experience different leveling problems mostly due to changes in the viscosity of the oil. If the hydraulic fluid is too cold or too hot it can make a huge difference as to where the elevator will stop.

Why does my hydraulic system on my RV not work?

We’re not sure about other types of RVs. One symptom is very slow or sluggish system (jacks and slides). Sometimes it will start out fine then slow down to a crawl and possibly stop. Another symptom is that the jacks or slides just don’t operate at all. The system appears to be fine. All the lights are normal, but just don’t DO anything.

How to troubleshoot RV hydraulic leveling jacks?

Walk around the RV and put eyes on each of the jacks to determine if there are any obvious issues preventing you from getting the jacks retracted. Look closely to see if there is any hydraulic fluid leaking anywhere as well.

Why does my 5th wheel hydraulic system slow down?

Note: This issue seems to be common on 5th wheels with hydraulic leveling systems. We’re not sure about other types of RVs. One symptom is very slow or sluggish system (jacks and slides). Sometimes it will start out fine then slow down to a crawl and possibly stop.

What happens when you press the button on a leveling jack?

Nothing can create that sinking feeling in your stomach quite like pressing the button to operate your leveling jacks and having nothing happen. That can make for a bad start to a trip or it can provide a terrible ending to an otherwise fun getaway. Whether your jacks are stuck up or down can make a big difference in the criticality of the fix.

What are the valves for front and rear leveling jacks?

With these motorized units, the two center valves are responsible for controlling the front jacks. You will need to open the center valves very slowly. Once the front jacks are retracted, you can then slowly open the valves controlling the outer rear jacks.
