Where is the fuse in a Dometic refrigerator?
Where is the fuse in a Dometic refrigerator?
On the outside of the RV, you’ll see a black box. You’re going to remove the cover and check the two fuses. One of the fuses is for the refrigerator control system, and the other one is for the AC cartridge heater.
Where are the fuses on a Dometic refrigerator?
I found 3 fuses on the back of the fridge. There were 2 blade style fuses and one automotive style glass fuse. Two of the three were under the circuit board cover. All fuses tested good visually and for continuity. Was 12 VDC present at the rear of the fridge?
Where to find the thermal fuse in Dometic dm2652?
Ceeminor, the thermal fuse I’m familiar with looks like a resistor, connected via spade terminals, with a clear plastic tube to protect from short circuits. This is represented in your schematics by item “Y”. Item “F”, I have no experience with. Item Y should be found close to the firebox. Thanks for the info!
When does the blue LED turn off on a Dometic refrigerator?
F) A blue LED simulates the refrigerator power through the thermal switch, when the blue LED turns off, the Dometic fridge turns off. This test was conducted with an absorption refrigerator boiler that did not have any fluids nor pressure in it.
What is the recall number on a Dometic refrigerator?
E) The Dometic part number 3850870019 recall 4 thermal switch set-point temperature is data logged by the meter on the right. F) A blue LED simulates the refrigerator power through the thermal switch, when the blue LED turns off, the Dometic fridge turns off.
Where was the fuse blown on the Dometic RV refrigerator?
TROUBLESHOOTING DOMETIC RV REFRIGERATOR 5 amp fuse blown. The 5 amp fuse location is in the back of the Refrigerator was blown causing the appliance to work only on LPG (GAS) mode.
When to use the reset button on a Dometic RV?
Finding the Dometic RV refrigerator reset button or process and knowing when to use it are some really crucial things you need to figure out before a trip. Your food and water fuel need to stay good and fresh inside the RV refrigerator. And if things go down the hill, you should not be stuck with finding location of a basic button.
Can a AC / DC Dometic refrigerator be troubleshooting?
AC/DC model Dometic refrigerators are fairly simple in troubleshooting. You will know that you have one of these models if the refrigerator has a compressor in the back (typically installed in boats and trucks). Most RV’s have gas absorption refrigerators and these can be more troublesome since there are more components that affect the cooling.
How to check the Dometic thermostat in a refrigerator?
The RM3662 has a method to check the Dometic thermostat which regulates the fridge cabinet (fresh food compartment) temperature. Use the control panel ‘TEMP. SET’ button to read the cabinet temperature by pressing the button once to display the current thermostat setting 1-5, where 5 is the coldest. The ‘TEMP.
