Locate the filter. Coleman furnaces use external air filters that are often attached to the outside of the furnace casing or in the return air duct. It might have a door or pull-out compartment for the filter. Open the door to access the filter.

Where the furnace filter is located?

The furnace filter is usually located inside of the blower compartment, where the return air enters the blower compartment. Most units have built-in furnace racks. The large metal furnace compartment contains a filter and blower.

How do I know if my furnace has a filter?

1. Horizontal HVAC unit – Furnace filter will be located on the intake side, slid into a rack.
2. Vertical HVAC unit with air moving upwards – You can find your furnace filter in the bottom door.

Do mobile home furnaces have filters?

Mobile home furnaces are specially designed to operate with these duct systems. Just like full sized furnaces, they utilize air filters to remove contaminants and keep air moving through the system correctly. Many mobile home furnace filters are installed directly at the grill that supplies ventilation to the furnace.

Where is the filter on my ComfortMaker furnace?

Open the door panel to gain access to your ComfortMaker furnace. You will find the filter near where the cold air enters the unit, either in the return duct or the entrance to the blower chamber. Simply slide out the old air filter and replace it with the new one part.

Where is my air filter located in my house?

The air filter is typically located at the point where the return duct enters the air handler. Larger houses often have more than one HVAC system. Each system will typically have at least one air filter. Therefore, your home may have air filters located at the air handler AND in the returns.

Can a furnace not have a filter?

Technically, you can temporarily run a furnace without a filter. … The consequences of running a furnace without a filter include: Poor air quality: For one, not having a filter in place means there is nothing to prevent dust and debris from being sucked into your furnace and recirculated throughout your home.

Is a furnace filter the same as an air filter?

While many people refer to air conditioning and furnace filters as if they’re different, this is not the case. Your furnace and your air conditioning system use the exact same filter, so there’s no need to worry about purchasing separate filters for each piece of equipment.

Do you have to turn off the furnace to change the filter?

To Change Your Home Air Filter, You’ll Need To Turn Off Your Furnace. To prevent the HVAC unit from turning on while you are changing the filter, make sure you turn the thermostat to the “off” position. … For maximum safety, disconnect power from your furnace system while you are doing maintenance.

What happens if I put my furnace filter in backwards?

When a furnace filter is placed backwards, the fibers can’t do their job properly. This means your furnace has to work harder to generate the same air flow, resulting in increased energy costs. Particles are also allowed to build up irregularly, making the furnace working even harder to draw air.

Article first time published on

How do you measure a furnace filter without a filter?

Disposable Furnace Filters – How to Measure Correctly If you do not have an existing air filter in your furnace, or your existing filter does not fit properly, you will have to measure the duct opening. To do so, you will need a flashlight and a stiff tape measure.

How often should you change your furnace filter?

In general, this is how often changing furnace filters needs to be done: For 1- to 2-inch filters, replace them every 1 to 3 months. For 3- to 4-inch filters, replace them every 6 to 9 months. For 5- to 6-inch filters, replace them every 9 to 12 months.

How many filters does a furnace have?

Most furnaces will have a V shape filter system; the system will take 2 filters. The filters go up into the plenum in a V shape. Make sure that when you re-install the top door, it goes over the furnace frame so it engages the safety switch.

How do you determine furnace filter size?

1. Follow these 3 easy steps:
2. Step 1 – Measuring Length and Width (L x W). …
3. Step 2 – Measure the thickness of your filter from front to back.
4. Step 3 – Put Your Measurements Together (L x W x D).
5. It’s as simple as that – You are now ready to buy the right filter for your AC or Furnace.

Will a furnace run with a dirty filter?

Why you should avoid running the furnace with a dirty filter In time, it can become clogged by a layer of dust, preventing air from flowing into the system. This can cause a number of issues: Low temperatures and poor airflow. High bills.

Can you run a furnace without a filter for one night?

If you run a furnace without a filter for one night, it won’t affect your HVAC system detrimentally. However, the longer you run your heating system without an air filter, the more contaminants will accumulate inside your heating unit’s inner mechanisms.

Which side is the airflow for furnace filter?

If you are looking at a furnace filter, find the arrow that indicates the proper air flow direction. That arrow must always face toward the furnace and away from the return duct that carries the air in need of heating or cooling.

How much does it cost to change a furnace filter?

Although flat filter designs offer the most savings upfront, they need to be replaced more frequently and may cost you more in the long run. Replacing these filters can cost anywhere from $40 to $200 a year.

What does a dirty furnace filter do?

A clogged furnace air filter will negatively affect the airflow throughout your house and HVAC system. The lack of fresh air in your furnace will cause the heat exchanger to become too warm and deactivate. Dirty filters indirectly cause short cycling issues and will make it hard to keep your home warm.

Whats a furnace filter?

What Is a Furnace Filter’s Job? Furnace filters are designed to capture dust, dirt, debris, and more that travel throughout our homes via the indoor air supply. Many people mistakenly believe a furnace filter does this job primarily to improve indoor air quality.

Do old furnaces have filters?

The filter is usually found near the blower compartment. In especially older models, the filter may be found located directly inside of the access door or in the grill. If you are unable to locate the filter in your furnace, contact a qualified furnace technician.

Does an electric furnace have a filter?

Like any furnace, electric furnaces have filters. Filters are a vital part of a furnace’s performance. The filter can usually be found within the blower compartment of the electric furnace. Even electric furnaces require filters and maintenance so that they can run well and provide you with warmth all winter long.

Where is the filter on a Miller furnace?

Your current filter will be located in between your cold air return duct and your unit’s blower motor. If you have trouble finding it, simply follow your return air duct down to where it meets with your furnace. When you’ve located it, slide it out of your unit. 4.

Why isn't my furnace filter dirty?

A filter is designed to catch all the air that goes through your air conditioning. Because of this, it needs to fit snugly inside the holder to have a chance at catching the air. … When that happens, the filter won’t get dirty because all that air isn’t going anywhere near it.

Why is my furnace only blowing warm air?

Check your thermostat’s settings, because your thermostat could be set to “Cool” which will limit your furnace from blowing hot air. Check that your air filter is clean and you don’t have a clogged air filter. … Blocked air ducts can limit return air flow, which can compromise your furnace’s heat exchanger.

Can I run my heat pump without a filter?

You can run your heat pump with no air filter for a short period of time; maybe 1 or 2 days. … The air filter collects dust and other contaminants from the air to keep your heat pump system running properly and is important to good indoor air quality.

What size filter does a Coleman furnace take?

Choosing a Replacement Filter Many Coleman furnaces use 16 x 25-inch filters, but it’s always important to check because you need the exact size for your model.
