Where are the slide out relay controls in the bedroom?

Back in the bedroom, there’s a 12V light switch right next to the bedroom slide control. I took both of them off the wall, removed the 12V supply wire from the light switch (used my meter to determine which was which), applied the 12V wire to the center pole on the slide switch…voila, bedroom slide works.

Where is the slide out controller on a motorhome?

For my motorhome, there are two slide out controllers attached to the “roof” of the middle basement compartment between the two main beams of the frame. One controller for the passenger side slide-out and one for the drive side slide-out. RV Masters charged $130 for the new controller and $140 for an hour of labor to install the controller.

What should you know about the slideout room?

ALWAYS MAKE SURE THAT THE SLIDEOUT ROOM PATH IS CLEAR OF PEOPLE AND OBJECTS BEFORE AND DURING OPERATION OF THE SLIDEOUT ROOM. ALWAYS KEEP AWAY FROM THE SLIDE RAILS WHEN THE ROOM IS BEING OPERATED. THE GEAR ASSEMBLY MAY PINCH OR CATCH ON LOOSE CLOTHING CAUSING PERSONAL INJURY.

What kind of slide out control do I Need?

USED RV/MOTORHOME POWER GEAR SLIDE OUT CONTROLLERS.CALL VISONE RV (606) 843-9889. (CLICK FOR MORE INFORMATION) USED DUAL CURRENT SENSING SLIDEOUT CONTROL AT-CSR-013 PRICE: $150.00 + $10.99 SHIPPING Click photo for more information. Used Dual-Current Slide-Out Control.

Where to look for a slide out mechanism?

Go to the rear of the arms to look and inspect the motors. These are for electric systems, if yours is hydraulic then you will have to inspect the pump, controls and the valves to the rooms. There could be a fuse for the pump that will need checked.

What to do when slide out room actuates?

1. Parking locations should be clear of obstructions that may cause damage when the slide-out room is actuated. 2. Be sure all persons are clear of the coach prior to the slide-out room actuation. 3. Keep hands and other body parts away from slide-out mechanisms during actuation.

What to do with a schwintek slide out room?

NOTE: Install transit bars (if so equipped) on the slide-out room during storage and transportation. Always make sure that the slide-out room path is clear of people and objects before and during operation of the slide-out. Always keep away from the gear racks when the room is being operated. Operation Extending Slide-out Room 1. Level the unit. 2.

Where can I get a Fleetwood motorhome slideout system?

Fleetwood Motorhome Slideout Systems Operations Manual 2 7 E. 7th St. Mishawaka, IN 46544 800-334-47 2 Fax 574-256-6743 Contents Introduction System Description Operating the Slideout System 2 Overriding the Slideout System 2 Troubleshooting (Electric Wiring) 3 Preventative Maintenance 4 Power Gear Limited Warranty 4 Fleetwoood

What do you need to know about electric slideout system?

1. Level the unit. 2. Verify the battery is fully charged and hooked-up to the electrical system. 3. Remove the transit bars (if so equipped). 4. Press and hold the IN/OUT switch (Fig. 1B) in the OUT position until the room is fully extended and stops moving. 5. Release the switch, which will lock the room into position.

What should I do if my slideout is not aligned?

Extend and retract the slide a few times and check for proper room flange sealing. If the room is not properly aligned, repeat steps 1 thru 6. *Depending on the size of your slide, you may need help moving the room by hand.

When to troubleshoot an RV slide out mechanism?

If you notice your RV slide room is experiencing some sort of malfunction, you may need to troubleshoot to diagnose the problem and figure out the best course of action. In order to pinpoint the proper solution, you have to first determine the type of RV slide out mechanism that’s equipped on your rig.
