What wires go to Herm on capacitor?

The C terminal on a capacitor is actually the common feed for the start winding of the compressor and fan (OPPOSITE side from the fan and herm plates on the capacitor). So, here are the compressor terminals: C goes to one leg of power. R goes to the other.

Which side of capacitor symbol is positive?

To tell which side is which, look for a large stripe or a minus sign (or both) on one side of the capacitor. The lead closest to that stripe or minus sign is the negative lead, and the other lead (which is unlabeled) is the positive lead.

Where are the red and black wires connected?

In the second box that holds the cable to the fixture, the active traveler from the first box is connected to the black to the second switch, and the red from the second switch is connected to the fixture. The second, unused traveler is also capped.

Can you replace an old switch with two red wires?

It’s a 4 gang box so a lot of other wires in there. In regards to the old switch, the black when to another black wire, one of the red wires went to another red, and the other red from the switch when to a black wire. And ground went to ground of course. Does that help? – cchiera Jul 30 ’16 at 18:39

What is the red wire for in an electrical outlet?

In standard 120-volt wiring, the hot wire is black, but it can also be red. In most cases, you see a red wire in an outlet box only in special circumstances. One is that the outlet is a 240-volt one, which requires an extra hot wire. Another is that the box is on a circuit three-way switch loop.

What’s the difference between a neutral and red wire?

One of the conducting wires — the neutral — is white; that color is mandated by the National Electrical Code. By convention, the other is usually black, but it could be red. Usually, though, you see a red wire only when the outlet is a 240-volt one or when it’s controlled by a switch.
