What kind of Furnace is in an Atwood RV?

ATWOOD 34,000 BTU EXCALIBUR 8535-IV-LD FURNACE Part# 37635 The Hydro Flame Excalibur 8535 IV-LD series furnace has been redesigned to be more efficient and quieter with a new burner and blower assembly. The new design has eliminated the obstruction and minimized the turbulence in the blower housing.

How many Atwood 8535’s are left in stock?

Only 2 left in stock – order soon. . Only 17 left in stock – order soon. . Only 5 left in stock – order soon. . Only 3 left in stock – order soon.

Why is the flame on my Atwood furnace not working?

It could also be the flame proving circuit. If the flame rod is out of alignmet, or if the flame is not touching the flame rod strongly or if the flame rod is dirty you will get these symptoms. I have also found that a poor ground from the circuit board can cause this as the flame is rectified through the flame to ground.

What kind of electrodes did the Atwood furnace have?

3–Atwood had two types of electrodes for ignition—If you have two wires going to electrode—one is ignition–other is temperature sensor (that tell circuit board there is a flame).

What are the parts on the Atwood 8535-iv?

ATWOOD FURNACE 8535-IV EXPLODED PARTS VIEW LINKS. Item# 1 Blower Wheel 33126. Item# 8 On/Off Switch 31092 (Replaces P# 36121) Item# 9 Gas Valve Replacement Coil 31000 NLA. *Not Shown* Time Delay Relay 48000. Item# 10 Combustion Air Wheel 33128. *Not Shown* Screw Door Latch 33847. Item# 14 Slide Plate 37411. Item# 15 Thermostat, Brown 38452 NLA.

What are the instructions for the Atwood hydroflame furnace?

Atwood HydroFlame Furnace Universal DC Ignition Control Kit Instructions 8535-iv Doc 38677

How is the Atwood Excalibur furnace installed in an RV?

Compact size installs both horizontally and vertically for better space utilization. All controls and crucial components are accessible from outside your RV for easy servicing. Access door sold separately. 1/box. ***This product is being replaced with Atwood’s new 32832 35522.

Is the burner assembly 32811 no longer available?

Please Note: Burner assembly 32811 is no longer available, do not order this kit if your burner assembly is worn out.

Atwood 8531-IV 37636 30K BTU RV Trailer Furnace 8531 Excalibur Camper Trailer RV Excalibur 8531 IV Designed for quieter nights The Excalibur 8531 IV series furnace has been redesigned to be more efficient and quieter with a new burner and blower assembly.

Is the Atwood model 8531 IV a brand new furnace?

The new design has eliminated the obstruction and minimized the turbulence in the blower housing. This removed the annoying frequency spikes, and the overall noise with an increase in the airflow. This Atwood Model 8531 IV Replacement Furnace is brand new and comes with full factory warranty.

How big is the Atwood DCLP LD camper furnace?

This removed the annoying frequency spikes, and the overall noise with an increase in the airflow. This Atwood Model 8531 IV Replacement Furnace is brand new and comes with full factory warranty. Fits openings 17″ W X 7 1/2 H. Furnace measures 16 1/2 wide x 7 3/8 high X 18 long. 30,000 btu rating.

How big is a 30, 000 BTU RV furnace?

Fits openings 17″ W X 7 1/2 H. Furnace measures 16 1/2 wide x 7 3/8 high X 18 long. 30,000 btu rating. This electronic ignition furnace operates on 12 VDC (7.6 amp) and LP Gas.
