What is the proper height for a trailer hitch?

The maximum recommended hitch ball height for trailers is 25″ from the ground measured to the center of the hitch ball.

How do you measure hitch height?

Step 1: Measure from the ground to the top of the hitch. Step 2: Level trailer, then measure from the ground to the top of the trailer coupler. Step 3: Subtract the height of the hitch ball (most are 2-1/2″ to 3″ high) from Step 2. The example would be 18″ minus 3″ = 15″.

Should my trailer be level when towing?

When towing, trailers should be level to improve stability, braking performance, and ground clearance. A level trailer will prevent poor towing characteristics, like sway, and uneven tire wear. If a trailer level is not possible the next best option is to have the trailer nose down a little.

What is the standard height of a tow ball?

between 350 and 420mm
The EC Directive 94/20/EC states that the towball height should be between 350 and 420mm with the vehicle in the ‘laden’ condition.

What is the coupler height of a Uhaul trailer?

18 inches
Jeff Jenkins, U-Haul’s towing expert, suggests using 18 inches as the trailer height in step two if you plan to tow a U-Haul trailer, as this is the standard coupler height for U-Haul trailers.

Does hitch height affect tongue weight?

In a word, yes, tongue height DOES affect tongue weight.

What happens if trailer is not level?

If the trailer is not level, either the front or the rear tires will be carrying more weight than the other. More weight on axle causes its tires to wear out quickly besides giving rise to other problems. If you apply little weight on the rear axle it will affect your handling and braking performance.

Is it better to have the trailer tongue higher or lower?

If a trailer is nose up too much, the tongue weight is low enough that the trailer may begin to sway. So in short, level is best. If level is not possible, then try to go slightly nose down.
