3. High Pressure: The term high pressure applies to systems with fan static pressures between 6 to 10 inches WC. Usually the static pressure is limited to a maximum of 7 inches WC, and duct velocities are limited to 4,000 fpm.

What gauge is high pressure ductwork?

High static pressure shall be constructed in accordance with SMACNA to a minimum 10” water gauge. d. All longitudinal and transverse duct joints shall be sealed. All ductwork shall be sealed to SMACNA Class ‘A’ standards.

What is considered medium pressure ductwork?

Duct Classification: Ducts shall be considered medium pressure when design velocities exceed 2000 fpm and static pressure is 2-inch W.G. or greater positive. Construct ducts in accordance with minimum reinforcement requirements for static pressure class of 4 inches positive.

What is considered low pressure ductwork?

Low pressure ductwork is hereby defined as ductwork subjected to velocities of 2500 fpm or less, and operating pressure of 2″ w.g. or less, positive or negative. … Connect air devices to low pressure ductwork with five-foot maximum length of flexible duct.

What is total pressure ductwork?

The total pressure in the duct system with the damper partially open equals the sum of the static pressure plus the velocity pressure. To measure static pressure in the duct system, connect a manometer as shown in Figure 11 on the left side.

What gauge is standard ductwork?

Largest Duct Dimension (width or height)Steel GaugeAt Joints C & DThru 12″26—–13″ – 18″24—–19″ – 30″24C-D @ 5′ cc D @ 10 cc31″ – 42″22—–

What are standard duct sizes?

Rectangular HVAC Duct Sizing Rectangular or square ducting comes in standard sizes ranging from 3 inches by 7 inches to 35 inches by 40 inches. Sizing is based on airflow needs per cubic foot per minute, as well as velocity.

What are low pressure HVAC systems?

Low pressure systems are chosen where duct space allows, where air noise is a consideration, and where particle conveyance such as wood chips or grain is not a requirement. Space limitations in modern buildings have restricted the size of air conditioning ducts and equipment.

What is a high pressure HVAC system?

Once the air is heated or cooled, a high-pressure HVAC system uses aspiration to create air currents. High pressure forces the air rapidly through the tubing to circulate it quickly into the home. This can heat or cool rooms much faster and allow for better climate control.

What are the duct pressure classes as per Smacna?

SMACNA breaks down the sealing of commercial ductwork into three classes: A, B, and C. Class A applies to static pressure of 4″ wg or more and requires all transverse joints, longitudinal seams and duct wall penetrations to be sealed.

Article first time published on

What is the max recommended length of flexible duct?

Flexible air connectors which are listed to UL 181 are allowed by the standard in lengths up to 14 feet. This product is specifically evaluated for the maximum length up to 14 feet, and the manufacturer’s installation instructions are reviewed to ensure proper installation up to this length.

Why is pressure low when velocity is high?

Because of Bernoulli’s principle. It said that summation of velocity head, pressure head and gravity head remains constant at every point of fluid. So when velocity of fluid high it pressure low same as vice versa.

What is medium pressure system?

Systems that operate at pressures of 50–3,000 psi (3–100 bar) are categorized as medium pressure chromatography systems. …

What happens when you reduce duct size?

The key takeaway here is that air moves from a larger to a smaller duct, the velocity increases. When it moves from a smaller to a larger duct, the velocity decreases. In both cases, the flow rate — the amount of air moving through the duct, in cubic feet per minute — stays the same.

What are the three pressures at work inside of a duct?

Airflow through a duct system creates three types of pressures: static, dynamic (velocity), and total. Each of these pressures can be measured.

Is WG and WC the same?

Pressure & Vacuum Terminology W.G. — Water Gauge (plus a height dimension). W.C. — Water Column or Column of Water.

How do I choose duct size?

To calculate the required equipment size, divide the HVAC load for the entire building by 12,000. One ton equals 12,000 BTUs, so if a house or office needs 24,000 BTUs, it will take a 2-ton HVAC unit. If you get an uneven number, such as 2.33 for a 28,000 BTU load capacity, round up to a 2.5-ton unit.

What size duct do I need for 2000 CFM?

Air flow – q – (Cubic Feet per Minute, cfm) (m3/s)Rectangular Duct Sizes (inches) (mm) x (mm)1700 (0.77)10 x 22 14 x 151900 (0.86)12 x 19 14 x 162000 (0.9)10 x 25 12 x 20 15 x 162500 (1.13)14 x 20 15 x 18

How many CFM can a 6 duct handle?

Example: How many CFM does a 6-inch duct have? A rectangular 6×6-inch duct has an airflow of 110 CFM. Bigger 6×12-inch ducts can handle 270 CFM airflow.

What is thicker 22 gauge or 24 gauge?

Which 22 or 24 gauge? 22 gauge is thicker. 22 gauge STEEL is 0.0299 in, 24 gauge STEEL is 0.0239 in.

What size is 16 gauge steel?

Number of gaugeApproximate thickness in fractions of an inchWeight per square meter in pounds avoirdupois145/6433.64159/12830.27161/1626.91179/16024.22

What metal is ductwork?

Made of galvanized steel or aluminum, rigid sheet metal is the most common type of ductwork. The thick, solid wall makes the duct very durable. The interior is known to trap dust and other particles, but the smooth surface is generally easy to clean.

What is a high velocity mini duct system?

High Velocity Mini Duct Systems High velocity, mini-duct systems are a way of handling and delivering cool and/or warm air throughout your home. They are a great solution if you live in homes with old, brick walls, wood beams, open floor plans, or new construction.

Can you zone a high velocity system?

Finally, it’s not very easy to combine a high-velocity system with “zoned “ HVAC. This is when different areas of the house are treated by separate units that can heat or cool at different temperatures from each other. You can achieve some degree of zoned HVAC with high-velocity.

Is high velocity HVAC more expensive?

However, the materials used in the high velocity air AC systems can cause the tubing to be more expensive than conventional AC systems. On the other hand, many high velocity installations end up being cheaper than traditional due to the lower construction costs.

What is pressure switch high high?

The “PSH” (pressure switch, high) activates when the air pressure inside the vessel reaches its high control point. … If this switch activates, something has gone wrong with the compressor control system, and the high pressure alarm (PAH, or pressure alarm, high) activates to notify a human operator.

What keeps the evaporator pressure from getting too high?

A low-pressure control in a refrigerating system can be used for: … Keeping the receiver pressure from getting too high. e. Evaporator pressure control.

What does an AC high pressure switch do?

The AC pressure switch is a safety switch that is mounted on both the high and low sides of the air conditioning system. It monitors the pressure of the refrigerant on its respective side of the system.

What is Class C ductwork?

Class C – for ventilation ducts in high pressure installations, 4. Class D – for special purpose installations, especially intended for higher energy efficiency. and hygiene standards.

Can flexible duct be used for return air?

Yes! You can use flex ducts for your return ducts. However, you have to make sure it fulfills all the necessary criteria. These include pressure checks, proper wrapping, and marking, airflow control, etc.

Is flex duct fire rated?

Flexible air ducts shall not penetrate a fire-resistance-rated assembly or construction. Flexible air connector lengths shall be not more than 5 feet (1524 mm) and shall not penetrate a wall, floor, or ceiling.
