Eaton’s Arc Fault Circuit Interrupter (AFCI) receptacles are designed to recognize a dangerous arc in your wiring and immediately break the flow of electricity, thus preventing your electrical system from becoming an ignition source for a fire.

What rooms need AFCI outlets?

Arc-Fault Circuit-Interrupter protection is required at outlets in all “kitchens, family rooms, dining rooms, living rooms, parlors, libraries, dens, bedrooms, sunrooms, recreation rooms, closets, hallways, laundry areas, or similar rooms,” per the current edition of the National Electrical Code (NEC).

What are AFCI outlets used for?

What is an Arc Fault Circuit Interrupter (AFCI) outlet and how does it work? AFCI outlets are designed to recognize many types of potentially hazardous arc-faults and respond by interrupting power, reducing the likelihood of the home’s electrical system being an ignition source of a fire.

Do all outlets need AFCI?

AFCIs are required on all 120-volt, single-phase circuits with 15 to 20 amps supplying receptacles in all dwelling rooms. If, for example, if you use your basement as a living room, playroom, or recreational room, then you will need to install an AFCI protection. However, basements (garages, attics, etc.)

What is the difference between a GFCI outlet and a AFCI outlet?

The AFCI (Arc Fault Circuit Interrupter) protects against fires caused by arcing faults. … The GFCI (Ground Fault Circuit Interrupter) is designed to protect people from severe or fatal electric shocks.

Should I install AFCI breakers?

AFCIs have proven so effective at preventing electrical fires that the National Electrical Code (NEC) requires AFCIs to be installed in almost every room in newly built houses. … The NEC also requires the installation of AFCIs in existing homes whenever an addition, an extra circuit, or even an extra outlet is added.

Where are AFCI required?

AFCI protection is currently required for all 15 and 20 amp branch circuits providing power to outlets* in residential family rooms, dining rooms, living rooms, parlors, libraries, dens, bedrooms, sunrooms, recreation rooms, closets, hallways, and similar rooms or areas.

Can an AFCI replace a GFCI?

Can a separate AFCI Receptacle and a GFCI Receptacle be used on the same circuit? Yes, they both can be used on the same circuit; however, the Dual Function AFCI/GFCI Receptacle offers the option of providing both AFCI and GFCI protection in a single device.

Why are AFCI breakers so expensive?

Poorly installed electronics (such as a ceiling fan) can cause your newly installed AFCI breaker to constantly trip. If this is the case, the electrician will need to fix the faulty wiring in order for the AFCI breaker to work properly and this will increase your overall cost.

Does refrigerator need AFCI?

Refrigerator Circuit A modern refrigerator requires a dedicated 20-amp circuit. … This circuit usually does not require GFCI protection unless the outlet is within 6 feet of a sink or located in a garage or basement, but it generally does require AFCI protection.

Article first time published on

Are all breakers AFCI?

The 2008 National Electrical Code (NEC) requires AFCI breakers in nearly all new construction. In 2017, the requirement was updated to require AFCI protection in virtually every room in a home.

Do AFCI outlets protect the whole circuit?

An AFCI device protects the entire circuit from the electrical panel through the downstream wire to the outlet, along with all appliances and equipment plugged into that circuit. If an AFCI device trips, it is most likely the result of a potentially dangerous arcing condition detected by the device.

What are two ways you can have AFCI protection?

This can be accomplished by installing AFCI circuit breakers then using GFCI receptacles at specific locations; or, there are combination AFCI/GFCI circuit breakers that can offer both types of protection to the entire circuit.

Why are AFCI breakers required?

The function of the AFCI is to protect the branch circuit wiring from dangerous arcing faults that could initiate an electrical fire. AFCI and GFCI technologies can co-exist with each other and are a great complement for the most complete protection that can be provided on a circuit.

How much does it cost to install AFCI?

Adding AFCI protection for an entire branch circuit typically requires the installation of a AFCI circuit breaker. These circuit breakers cost about $30 – $50 each, and installing them means replacing existing circuit breakers, which I don’t consider to be a good “starter” electrical project.

When was AFCI required?

In 1999, AFCIs became a requirement in the National Electrical Code (NEC®). An AFCI breaker provides a higher level of protection than a standard circuit breaker by detecting and stopping a hazardous arcing condition before it can become an electrical fire.

Where are AFCI breakers required 2020?

In the 2020 edition of the NEC®, Section 210.12 requires that for dwelling units, all 120-volt, single-phase, 15- and 20-ampere branch circuits supplying outlets or devices installed in dwelling unit kitchens, family rooms, dining rooms, living rooms, parlors, libraries, dens, bedrooms, sunrooms, recreation rooms, …

Is AFCI required for lights?

AFCI requirements. The NEC requires that virtually all branch circuits for lighting and receptacles in a home must have arc-fault circuit-interrupter (AFCI) protection. This is a form of protection that guards against sparking (arcing) and thereby reduces the chance of fire.

How long do AFCI breakers last?

An AFCI or CAFCI circuit breaker should last 30 to 40 years, with an average of 35 years.

Can you replace a AFCI breaker with a regular breaker?

As long as you do not leave it in place beyond your troubleshooting, a standard breaker could be put in the panel in place of the AFCI. … If this doesn’t solve the problem, hire an electrician to install a new arc-fault breaker in the electrical panel.

Are AFCI breakers required in older homes?

While many new homes have AFCI breakers, many older homes do not, and that is deemed to be acceptable since they were not required during the code year the house was built. … While your city may not require them, AFCI’s may still be a worthy investment.

Does a microwave need a AFCI?

A dedicated 20-amp circuit is needed to feed the microwave oven. Since the appliance is plugged into an outlet, AFCI protection is required.

Does a washing machine need to be arc-fault protected?

Therefore, by default, the clothes washing machine in a dwelling unit laundry area will be AFCI protected. Nearly every room/ area in a dwelling unit requires AFCI protection, so no matter where you put a clothes washer, it will be AFCI protected in a newer home.

Are arc-fault breakers required in bathrooms?

Note: Arc-Fault Circuit Interrupters (AFCIs) requirements have not expanded to the entire dwelling unit (to include bathrooms, basements and crawl spaces). … Although some changes were made to the AFCI section in the code, they apply only to dorms and hotels/motels.

Does an AFCI outlet protect downstream?

It does protect all downstream outlets (but not those that are upstream) if it is installed in the first location in a “Daisy Chain” and the rest of the chain is attached to the protected terminal of the AFCI. As a note, there are combination AFCI-GFCI units that provide full protection for all down-chain outlets.

How many receptacles can be on a 20 amp circuit?

The answer to the question how many outlets on a 20 amp circuit is ten outlets. Always comply with the 80% circuit and breaker load rule, allowing a maximum load of 1.5 amps per receptacle. Remember that your circuit, wire sizes, and outlets must be compatible to avoid overheating and electrical hazards.
