T12 bulbs are the oldest type still in use in some fluorescent fixtures. … T8 bulbs are more expensive than T12 bulbs but will start much faster. … T5 bulbs are a smaller version of their big brothers.

What are the 3 types of regular fluorescent lamp?

• T12 bulbs are the oldest type still in use in some fluorescent fixtures. …
• T8 bulbs are more expensive than T12 bulbs but will start much faster. …
• T5 bulbs are a smaller version of their big brothers.

How do I choose fluorescent lights?

First, you will need the diameter or how wide it is around. This is expressed as a number such as T8 or T12. The “T” stands for tubular, and the number is a measurement of the diameter in 1/8″ increments. So a bulb with a 1″ diameter would be a T8—eight 1/8″ increments.

How do I know if my ballast is T8 or T12?

If no markings are available, the size in diameter of the tube is the easiest way to determine the type you have installed. T8 tubes are 1-inch in diameter and T12 tubes are 1 1/2 -inch.

What is the difference in fluorescent tubes?

The major physical difference between T5 and T8 light bulbs is the length and diameter of the tube itself. The T5 tends to be slightly shorter than the T8 tube, and is significantly smaller in diameter. This factor is important to consider when looking at your fixture, because the two tubes are not interchangeable.

What is the difference between T8 and T12 fluorescent bulbs?

The main difference between T8 and T12 tubes is the tube’s diameter. T12 tubes are 1.5″ in diameter while T8s are just one inch. All other things—socket sizes, lengths, distance between pins—are the same. T8 LED tubes won’t fall out if you try to install them in a T12 fixture—they’ll fit just fine.

Does T8 fit in T12?

T8 tubes are simply 1 inch in diameter versus the 1.5 inch diameter of T12 tubes. In an effort to make LED tube lights compatible with the internal dimensions of most fixtures, you will find that most LED tube lights feature a T8 or 1 inch diameter. They can indeed be used in T12 fixtures.

Can you replace a T12 ballast with a T8 ballast?

The easiest and lowest price option to replace a T12 is a T8 linear fluorescent. They have become the go-to option for pre-existing T12s. If you still have magnetic ballasts, switching to a T8 will require a ballast swap. Another option is to move forward with an LED retrofit.

What does T8 and T12 mean?

A T12 lamp (on the left in the figure below) is therefore twelve-eighths of an inch, or one-and-one-half inches (3.81 cm), in diameter. A T8 lamp (on the right in the figure below) is eight-eighths of an inch, or one inch (2.54 cm), in diameter.

What is the difference between T4 and T5 bulbs?

There are many types of fluorescent lights available but the main difference between the T4 and T5 lights are their efficiency or their watt consumption and lumen output, as well as the thickness of the tubes. The T4 has a half-inch diameter, while the T5 is five-eighths of an inch.

Article first time published on

How do I identify fluorescent tubes?

Lamps are typically identified by a code such as FxxTy, where F is for fluorescent, the first number (xx) indicates either the power in watts or length in inches, the T indicates that the shape of the bulb is tubular, and the last number (y) is the diameter in eighths of an inch (sometimes in millimeters, rounded-up to …

Are there different types of fluorescent bulbs?

Types of Tube Light Bulbs While there are multiple types of LED and fluorescent tube lights, the three most common are T12, T8 and T5. The terminology comes from “T” for “tubular” and the diameter of the bulb in eighths of an inch, so “T8” represents a tube of 8/8ths of an inch, or 1 inch.

What's better T5 or T8?

T5 lamps are smaller and more efficient than T8 bulbs. T5 lights are the winner between the two, they do cost about 2x more than T8 options. While T8s are cheaper upfront, T5s are a more affordable option long-term and are great for most growing needs.

Which is better LED or T5?

LEDs also offer increased light efficiency when dimmed as opposed to T5 fixtures and usually produce more lumens per watt in general, which decreases energy usage and thus, energy costs. A lower wattage of LED luminaire will usually be just as efficient, sometimes more, as a higher wattage T5 lamp.

What is T5 and T8 light?

T5 lamps have a diameter equal to 5 times an eighth of an inch, or 5/8″. These lamps are approximately 40% smaller than T8 lamps, which are one inch in diameter, and almost 60% smaller than T12 lamps, which are 1½” in diameter. … T5 lamps have a miniature bi-pin base while T8 and T12 lamps use a medium bi-pin base.

Can I replace T8 with LED?

Type A – LED tube has an Integrated Driver for use on Existing Fluorescent Ballast. Type A LED tubes need an existing T8 electronic ballast to operate. … All you need to do is remove the existing T8 fluorescent lamp and install a new T8 LED Type A lamp.

Are fluorescent tubes being phased out?

The sale of halogen lightbulbs will be banned in the UK from September as part of ministerial efforts to cut carbon emissions. A ban on fluorescent lighting, which is mostly used in offices, will follow in September 2023.

Are T12 bulbs being discontinued?

In effect since July 2012, the legislation eliminates nearly all 4-foot T12 lamps, some 4-foot T8 lamps, most 8-foot T12 lamps, and almost all standard halogen PAR38, PAR30 and PAR20 lamps from the market. T12 technology is over 80 years old. Since that time, lamps and bulbs have been developed that just work better.

What is a T5 fluorescent tube?

A T5 is a type of fluorescent tube. It differs from a T12 and a T8 in its diameter. All T5s are 5/8ths of an inch (T8s are exactly 1inch thick and T12s are 12/8ths or 1.5 inches thick). T5s are 16mm in diameter making them the thinnest fluorescent tube out of the three.

Is F40 same as T12?

This is calculated in 1/8″ increments. This means a T8 lamp is 8/8ths of an inch in diameter, or 1 inch. A T12 is 12/8ths of an inch, or 1.5″ in diameter. … All F32 and F40 lamps are essentially 4 foot long lamps (47″ if you don’t count the pins).

Are T5 and T10 bulbs the same?

“Five-sided lighting” , Bulbs uses five-sided lighting in order to increase brightness and wider angle of brightness area. In fact, the history of T5 is same as late evolution of T10. We got to solve the problem that the illuminate breadth is not enough, resulting in multi-faceted illumination.

Which is brighter T12 or T8?

The Standard T12 lamp produces 2,650 initial lumens per lamp. The standard T8 produces 2,800 initial lumens per lamp, 6% brighter. But the standard T12 lamp produces 2,300 design lumens and the T8 produces 2,660 design lumens. … Design Lumens are the average lumen output of the lamp after 40% of its rated life.

What does G13 mean in lighting?

You can recognize a T8 tube from it’s 28mm diameter. The socket is called G13 this because the 2 pins are 13mm apart from each other. . A T8 tube can work on an electronical ballast using a fixture without a starter. As with a conventional ballast, a fixture with a starter.

Are T5 and T12 bulbs interchangeable?

T5 bulbs use about 45% less energy than T12s. For some applications, one T5 bulb can replace two T12 bulbs, providing even greater energy savings (a process called “de-lamping.”) The typical T12 four-lamp fixture uses 172 watts of power between the lamps and ballast.

What is the difference between magnetic and electronic ballast?

A magnetic ballast uses coiled wire and creates magnetic fields to transform voltage. … An electronic ballast uses solid state components to transform voltage. It also changes the frequency of the power from 60 HZ to 20,000 HZ or higher depending on the ballast.

What is the difference between shunted and Unshunted sockets?

Shunted sockets feature internally connected electrical contacts. This provides a single track for the electrical current to travel from the ballast, through the tombstone, or socket, and to the lamp’s pins. … Non-shunted sockets have contacts that are not joined or connected.

Is G8 bulb same as T4?

Answer: T4 is bulb size i.e. length and maybe diameter- 1.77″long (44.95mm). G8 is the base dimension – it has two pins, 1mm in diameter, and about 13mm or 13.5mm long (very close to 1/2 inch) and 8mm apart. … A T4 bulb may or MAY NOT HAVE a G8 base.

What bulb is smaller than T5?

The “T” in T5 indicates the bulb is tubular shaped, while the “5” denotes that it is five eighths of an inch in diameter. The other common lamps are the larger T8 (eight eighths inch = 1″) and T12 (twelve eights inch = 1½” tubes).

What does T4 mean in fluorescent tube?

T4 (13mm Diameter) T4 tubes have a diameter of 13mm. They’re compact and easy to install making them perfect for illuminating kitchen counters and worktops as well as under cabinet lighting. These tubes will generally use between six and eight times less energy.

What is the difference between T5 T8 and T12?

So a T5 is 5/8ths of an inch, a T8 is exactly one inch thick (i.e. 8/8ths) and a T12 is 12/8ths or one and a half inches thick.

Can I replace my fluorescent tubes with LED?

Yes, you can replace fluorescent tubes with LED tubes or LED-integrated fixtures. If you just want to replace the bulbs, you can use plug-and-play, direct-wire, or hybrid LED tubes. Plug-and-play tubes are the easiest to install as they do not require any rewiring to the fixture.
