A typical residential AC unit has two copper lines that both exit the building exterior and run to the outside condenser unit. Only one of these copper pipes, the cold line, should be insulated. This is called the “suction” pipe and is typically the larger of the two pipes.

Do you insulate both AC lines?

7 Answers. This is the answer to your actual question: “insulating the coolant pipe inside the actual AC unit itself.” As you correctly observed, if the outside pipe “should” be insulated (it should), then the inside pipe “should” also be insulated for all the same reasons everyone pointed out.

What happens if the suction line of an air conditioner is not insulated?

Q: What happens if the suction line of an air conditioner is not insulated? A: It sweats, drips and adds more heat needing to be rejected by the condenser. The line will sweat with condensate and drip water.

When should both liquid and vapor lines be insulated?

Liquid lines generally are insulated. They are warm to hot (110°F (43.3°C) for air-cooled). If liquid lines pass through a space that is warmer than the refrigerant (i.e. the roof of a building at roof level), or if they could be considered hot enough to pose a safety risk, then insulation should be added.

Should AC drain lines be insulated?

No. Building & mechanical codes do not require insulation on A/C condensate drains, based on a reading of the current U.S. Energy Code that I will excerpt here.

Which HVAC line is insulated?

Refrigerant Lines The larger line typically carries a cool gas and is insulated. This is commonly referred to as the suction line, but it is also called the return line or vapor line. The smaller uninsulated line typically carries a warm liquid. It is most often called the liquid line.

Do refrigerant lines need to be insulated?

Liquid lines generally are insulated. … If liquid lines pass through a space that is warmer than the refrigerant (i.e. the roof of a building at roof level), or if they could be considered hot enough to pose a safety risk, then insulation should be added.

Do you have to insulate both lines on a heat pump?

As for insulating lines, the liquid line is always the liquid line in a HP. It is never below the dew point so it does not need insulation. The reason for the insulation is to keep it from sweating, it has not real job in the thermal loss aspect. The only time we insulate two lines is in refrigeration.

Why is only the suction line insulated?

The suction line is insulated because it is the cold line and any extra heat it picks up on the way to the compressor wastes energy in the compressor. The liquid line is warmer than the ambient air, so it actually gives up heat to the ambient air making the system more efficient.

Why does the suction line have to be insulated?

Insulating the suction line is done to prevent condensate from developing and dripping off. This condensate drip can cause water damage to the material under it or cause a slip hazard for people walking below it.

Article first time published on

Should AC pipes be cold?

The Copper Pipe (Suction Line) should be sweating and cold to the touch during a hot day. If it is not cold, your compressor could be off (bad capacitor/ hard start kit) or low on Refrigerant.

How do I stop my AC pipe from sweating?

Wrapping your AC ductwork is an effective way to prevent condensation. Duct wrap has a foam insulation inner layer and a foil outer layer. Cleanly wrap it around the AC duct and fasten with duct tape near the joints.

Why are AC pipes sweating?

Pipe sweating occurs because cold air holds less water vapor than warm air. When a cold pipe touches the hot, moist air around it, the temperature around the pipe drops and the air reaches its dew point. This causes the water vapor in the air to become a liquid and collect on the side of the pipe.

Does mini split drain line need to be insulated?

Mini splits drain do need insulation. Condensate water produced by mini splits is cold. Thus, the drain pipe must be insulated to prevent condensation. However, if the drain pipe is concealed, the wall or floor acts as insulation.

How cold should the refrigerant line be?

The suction temperature should be above 35°F and below 65°F entering the compressor and the discharge line temperature should be below 220°F and above 150°F (typically) on a properly functioning package unit.

What are the 2 AC lines?

There are two copper lines that run between the condenser and the evaporator coil. The larger line is known as the suction line, return line, or vapor line. It carries cool gas, so it must be insulated with tubing. The second copper line is small and bare, and it is commonly known as the liquid line.

Where is the suction line on an air conditioning or refrigeration system is insulated to?

If you have an air conditioner, you have a suction line–that’s the “cold” copper line that runs between the compressor and the evaporator, and it carries the cool refrigerant back to the compressor to be turned back into liquid. When your HVAC system is new, this line is insulated air-tight with 3/4″ insulation.

What type of tubing should be used to install refrigeration lines?

Hardened copper tubing is used for water lines, commercial refrigeration and HVAC. This type of tubing is joined using grooved, compression, crimped, or sweat connections.

What state does refrigerant enter the compressor?

Circulating refrigerant enters the compressor in the thermodynamic state known as a saturated vapor and is compressed to a higher pressure, resulting in a higher temperature as well.

Which line connects the evaporator to the compressor?

The suction line connects the evaporator to the compressor, the discharge line connects the compressor to the condenser, and the liquid line connects the condenser to the expansion device. The expansion device is typically located at the end of the liquid line, at the inlet to the evaporator.

Why is my air conditioner pipe freezing up?

The main reason why your AC lines are freezing is because your evaporator coils are getting too cold. The evaporator coil is filled with refrigerant which cools the air in your HVAC system. … The ice can eventually accumulate on the refrigerant line.

Is it normal to have condensation on AC?

Condensation is normal for properly running air conditioning systems. Excess condensation, like sweating ducts and drips from outside the unit cabinet indicates a problem with your unit and points to an HVAC system issue that requires emergency HVAC repair service.

Should my exterior AC drain pipe be dripping water?

Under normal conditions, the exterior AC condensate drain pipe should only drip water or produce condensation while the air conditioner is turned on. The small puddle of water this process creates should dry up quickly in warm weather.

What do I do if my AC isnt blowing cold air?

Try cleaning your air conditioner’s filter and the coils to see if improving the airflow fixes the problem. If there is ice buildup, you’ll need to run the unit with just the fan in order to melt it off. If that doesn’t get the unit blowing cold air again, it could be refrigerant levels are low (see below).

Why is my AC blowing cold air but not cooling room?

Reasons why your air conditioner is running but your house is not cool can be: clogged air conditioner vents, thermostat is defective, or internal issues that need professional help.

Does pipe insulation stop condensation?

We can prevent condensation from occurring by insulating the pipe with enough insulation to keep the air around the pipe from dropping below the dew point. … It depends on the dew point of the air, which fluctuates according to the ambient temperature and the relative humidity.
