Is the Norcold 1200 lrim running on propane?

My infamous Norcold 1200 LRIM seem to be running ok, but only on Propane. When I try to switch the mode to AC, I get the no. AC code. Does anybody have any ideas. The fuse you are looking for is the automotive type that is glass with contacts on the ends. It is in the refer bay outside.

When did the Norcold 1200 lrim cooling unit fail?

The first failure occurred at 25,000 miles or Jan of 2006, total cooling unit failure which was replaced in Ft Myers Camping World for $1687.00. Unit performed marginally until March of 2009 until it exploded and caught fire while we were having lunch. Fortunately we extinguished the fire with minimal coach damage.

Is the Norcold gas absorption model refrigerator safe?

Nearly everyone with a Norcold RV refrigerator has heard of the dreaded high temperature sensor recall. Is your refrigerator safe?! Norcold gas absorption model refrigerators (RV models) have cooling units that operate through the heating, evaporating, and condensing of an ammonia solution.

What is the service manual for a Norcold refrigerator?

This service manual provides maintenance, diagnostic, and repair information for NORCOLD, INC. model 1200XX/120X-IMXX gas absorption refrigerators.

What kind of refrigerator is the Norcold 1200lrim?

The Norcold 1200LRIM is a 12 cubic foot in size gas-absorption refrigerator designed for use in a recreational vehicle. The unit comes equipped with an ice maker, crispers, tall bottle drawer, door bins, adjustable shelves and door latches to prevent the refrigerator from opening during travel.

When did I replace the cooling unit on my Norcold refrigerator?

When I tried to get the heaters replaced, the Tech couldn’t remove it from the stack it lives in, due to excessive corrosion, so with the then 14 year age of the unit and other signs of aging, I ended up replacing the whole cooling unit with the “Amish” one. That was in November 2011. All has been well since then.

Where is the fuse on a Norcold refrigerator?

The fuse you are looking for is the automotive type that is glass with contacts on the ends. It is in the refer bay outside. It is behind a black plastic cover on a circuit board. The cover is behind the icemaker valve. To get to mine I have to loosen the mounting for the icemaker and remove the screws holding the black plastic cover.

Which is better Amish or Norcold refrigerators?

The Tech that diagnosed mine as needing a new CU told me he had replaced dozens of cooling units, many with Amish, the rest with Norcold. His experience with them was very positive. He praised their beefier build and much better service record.

When was the first Norcold 1200 lrim refrigerator failure?

It was equipped from the factory with a Norcold 1200LRIM. The first failure occurred at 25,000 miles or Jan of 2006, total cooling unit failure which was replaced in Ft Myers Camping World for $1687.00. Unit performed marginally until March of 2009 until it exploded and caught fire while we were having lunch.

Where is the no AC code on my Norcold refrigerator?

Thanks to this forum my “no AC” error code was easy to diagnose, although lifting that black box cover on the rear of the fridge yielded a few choice words of frustration. The 5 amp auto fuse under the black box cover was good, but the Buss glass fuse, 5 amp 250 volt, was black from end to end.

The fuse you are looking for is the automotive type that is glass with contacts on the ends. It is in the refer bay outside. It is behind a black plastic cover on a circuit board. The cover is behind the icemaker valve. To get to mine I have to loosen the mounting for the icemaker and remove the screws holding the black plastic cover.

What does no AC alarm mean on Norcold refrigerator?

“no“ “AC“ Audible alarm also. AC voltage is unavailable to the refrigerator control. – That the refrigerator plugged into a serviceable outlet. – That the fuse or circuit breaker of the vehicle is intact. – That the vehicle generator is operational (if applicable).

My infamous Norcold 1200 LRIM seem to be running ok, but only on Propane. When I try to switch the mode to AC, I get the no. AC code. Does anybody have any ideas. The fuse you are looking for is the automotive type that is glass with contacts on the ends. It is in the refer bay outside.

What does the Norcold 1210 error code mean?

Norcold 1210 refrigerator error codes. Fault Codes. Fault Code Meaning. Corrective Actions. No display. DC voltage is unavailable to the refrigerator control panel or the refrigerator is OFF. – That the refrigerator is ON. – That the battery charging equipment of the vehicle is operational.

What happens if you bypass the Norcold recall?

As a result of false triggers for the Norcold recall, operators get into the habit of resetting or bypassing the Norcold recall. This is a bad habit, if there is a failure of the fridge and one bypasses the recall, or turns off the ARP Control, a dangerous situation may occur.

Why does my Norcold refrigerator have no AC?

I had the same “no AC” when one of the heaters failed. This was diagnosed by a Tech when I was near Temecula, CA.

Where can I find a list of Norcold replacements?

While most are on other subjects there are a number that refer to the Norcold. Some are about replacement with a residential refrigerator. Try the bottom of page 5, or pages 7 and 8. When you click on the link be sure to go back to page 1 of that thread to see all the posts.

The first failure occurred at 25,000 miles or Jan of 2006, total cooling unit failure which was replaced in Ft Myers Camping World for $1687.00. Unit performed marginally until March of 2009 until it exploded and caught fire while we were having lunch. Fortunately we extinguished the fire with minimal coach damage.

I had the same “no AC” when one of the heaters failed. This was diagnosed by a Tech when I was near Temecula, CA.

Can a Norcold refrigerator be used in an RV?

Most RV’s have gas absorption refrigerators and these can be more troublesome since there are more components that affect the cooling. The first thing to know is that the cooling units on every Norcold gas absorption refrigerator are gravity operated and MUST be level in order to run properly.
