How do you reset the antenna on TracStar?

Reset the antenna by pressing the on button on the TracStar display (IDD). Once the IDD reads “scan align” press the on button again and the IDD will read “idle hold”. Put the antenna in “show motion” ( see Section 25 ). Check for proper range of motion (circular movement).

What should the Ba Be on a TracStar satellite?

Press the arrow button 2 times, the display will read on the top line “BA XXX (some numbers) E XXX (some numbers)”. The number directly to the right of the BA should be between +/6000. If the numbers are too high then the AZ fault may be caused by a bad CPU/Gyro or Gyro ribbon cable ( see Section 7 item F ).

How can I get TracStar to move my dish?

Call TracStar for technical assistance. Move the white dish manually up and down.There should be very little resistance and the dish should make contact with the upper and lower limit switch. Check the black or brown pulley located behind the white reflector dish that the elevation belt rides on ( see Section 7 item I ).

What is the tuner data used for TracStar?

Tuner data-Used by TracStar technical support. Used to verify reception of the satellite signal to the Antenna. Will read all zeros in scan align, when the antenna goes to “wide scan” the zeros should disappear and the satellites azimuth, elevation and signal strength will appear.
