Turn off power at circuit-breaker box.Remove lens or diffuser panel from light.Remove lamps or bulbs.Remove ballast cover. … Uncap black and white wires and test to ensure that power is off.Separate wires from existing fixture.Remove fixture base from ceiling.

How do you open a fluorescent light box?

1. Turn off the light fixture that you want to replace.
2. Use a step ladder to reach the fixture while giving yourself space to work.
3. Locate the textured prongs on the outer part of the fixture. ( …
4. Push the prongs in with your fingers. (

How do you remove a 4 foot fluorescent light cover?

The lens is a U shape and covers the sides and bottom of the lights. The sides of the lens sit on a ledge with a small lip, and you can push it out of place easily. To remove a wraparound fluorescent light cover, simply grab one long side, push up, and then pull it down. Do the same with the other side.

What are the signs of a bad ballast?

• Buzzing. If you hear a strange sound coming from your bulbs or light fixture, like a buzzing or humming noise, that’s often a sign your ballast is going. …
• Dimming or flickering. …
• No lights at all. …
• Changing colors. …
• Swollen casing. …
• Burn marks. …
• Water damage. …
• Leaking oil.

How do you remove fluorescent light covers without clips?

If your kitchen is lit by a single fluorescent bulb instead of several, its cover may be held in place with a nut on the side. Use pliers or a wrench to twist this nut counterclockwise. When it comes off all the way, you can slide the bulb cover away from the nut.

How do you open an old fluorescent light fixture?

The fixture has two levers holding its frame securely in place. But once you unlatch these levers, you don’t need to worry about the frame falling out. It will open just a few inches on one side. From there, slide it toward the open side in order to activate its hinges.

How do you remove a square light fixture cover?

Use a screwdriver to take out screws holding covers attached to the ceiling. Some covers swing downward on a hinge or hinges, which hold the cover while you change out the bulb underneath. Other cover styles remove completely from the fixture.

How do I know if my ballast is T8 or T12?

If no markings are available, the size in diameter of the tube is the easiest way to determine the type you have installed. T8 tubes are 1-inch in diameter and T12 tubes are 1 1/2 -inch.

How do I know if it's the ballast or bulb?

One probe of the multimeter should touch the hot wire connections, while the other touches the neutral wire connections. If the ballast is good, an analog multimeter has a needle that will sweep to the right across the measuring scale. If the ballast is bad, then the needle won’t move.

Why are my fluorescent lights flickering?

If your fluorescent bulbs flicker, most likely the problem is with the bulb itself. If the bulb is very dark on either end, it may be defective and burned out. The best way to test the functionality of a bulb is to put it into a fixture you know works. … Flickering fluorescent lights can also be a result of temperature.

Article first time published on

How do you remove an old ceiling box?

Turn the screws counterclockwise with a screwdriver or a drill to remove them from a box attached to a board between the ceiling joists. Pull the box from the ceiling. As you pull the box from the ceiling, carefully remove the electrical wires from the box.

How do you replace a ceiling electrical box?

Remove the screws holding the ceiling box, using a screwdriver. Pull the box carefully from the ceiling so you don’t damage the wiring. If the box is nailed in the ceiling, place a piece of wood inside the box and strike it with a hammer to loosen the box. Pull the box carefully from the ceiling.

How do you replace a fluorescent light fixture in a kitchen?

1. Turn off power at circuit-breaker box.
2. Remove lens or diffuser panel from light.
3. Remove lamps or bulbs.
4. Remove ballast cover. …
5. Uncap black and white wires and test to ensure that power is off.
6. Separate wires from existing fixture.
7. Remove fixture base from ceiling.

How do you remove a square ceiling light cover without screws?

1. Locate the finial (the fancy decorative bit in the middle of the dome).
2. Turn the finial anticlockwise to loosen it. Keep one hand on the dome. As you turn the finial the dome should start to come away from the base.
3. Completely unscrew the finial and the dome should come away in your hand.

How do I remove a spring light ceiling cover?

Use a putty knife or other thin blade to carefully pull the cover straight down evenly about 1/2″. You should then be able to use your fingers to slowly pull the cover down a little more. Each clip has a hook at the top end. When you feel resistance from the hook, do not continue pulling.

How do you remove a plastic square ceiling light cover?

Access the plastic ceiling light, using a stepladder. Remove the plastic light shade by twisting it counterclockwise. Alternatively, loosen the fitter screws around the light base to remove the shade.

How do you know if fluorescent ballast is bad?

1. Flickering. …
2. Buzzing. …
3. Delayed start. …
4. Low output. …
5. Inconsistent lighting levels. …
6. Switch to an electronic ballast, keep lamp. …
7. Switch to an electronic ballast, switch to a T8 fluorescent.

How much does a ballast cost?

A replacement ballast costs about $10-25 depending on capacity and brand. The bite is that an electrician trip charge (which includes 30 or 60 minutes work) is going to be $75-150 probably – for about 5 minutes work on each light fixture.

How long do ballasts last?

According to the Certified Ballast Manufacturers Association, the average magnetic ballast lasts about 75,000 hours, or 12 to 15 years with normal use. The optimum economic life of a fluorescent lighting system with magnetic ballasts is usually about 15 years.

Can I replace a T12 bulb with a T8?

The easiest and lowest price option to replace a T12 is a T8 linear fluorescent. They have become the go-to option for pre-existing T12s. If you still have magnetic ballasts, switching to a T8 will require a ballast swap.

Can I put a T8 bulb in a T12 ballast?

T8 tubes are simply 1 inch in diameter versus the 1.5 inch diameter of T12 tubes. In an effort to make LED tube lights compatible with the internal dimensions of most fixtures, you will find that most LED tube lights feature a T8 or 1 inch diameter. They can indeed be used in T12 fixtures.

Are T12 bulbs being discontinued?

In effect since July 2012, the legislation eliminates nearly all 4-foot T12 lamps, some 4-foot T8 lamps, most 8-foot T12 lamps, and almost all standard halogen PAR38, PAR30 and PAR20 lamps from the market. T12 technology is over 80 years old. Since that time, lamps and bulbs have been developed that just work better.
