Determine how thick you want the concrete.Measure the length and width that you’d like to cover.Multiply the length by the width to determine square footage.Convert the thickness from inches to feet.Multiply the thickness in feet by the square footage to determine cubic feet.

How do you figure concrete footings?

1. Determine how thick you want the concrete.
2. Measure the length and width that you’d like to cover.
3. Multiply the length by the width to determine square footage.
4. Convert the thickness from inches to feet.
5. Multiply the thickness in feet by the square footage to determine cubic feet.

How do I calculate concrete isolated footing?

1. Volume = H/3 (A1+A2+(√A1 x A2)
2. A1 = 2 x 1.5 = 3 Sqm.
3. A2 = 0.5 x 0.3 = 0.15 Sqm.
4. H = 0.15m.
5. Now Volume = 0.15/3 x (3+0.15+(√3 x 0.15)
6. Now Volume = 0.05 x (3.15+0.67)
7. Volume = 0.19 m3
8. Volume (V) = 0.19 m3

How do you calculate linear feet for footings?

Multiplying the width by the linear footprint of the structure will give you the size in linear feet. To convert linear feet into square feet, you can divide the width by 12. For example, an 18-inch footer is 1.5 square feet per linear foot.

How thick should a concrete footing be?

For masonry or concrete construction, the minimum foundation wall will be 6 inches. The minimum reinforced concrete footing thickness will be 6 inches or 1-1/2 times the length of the footing projection from the foundation wall, whichever is greater.

How deep should footings be for a 3 foot wall?

For a wall that will be higher than 750mm make the footing three times the thickness. All footings should be a minimum of 150mm (6″) in depth, with the bottom 350 – 400mm (14-16″) below ground level on most soils. For clay soil however, thicker and deeper footings should be used.

How wide and deep should footings be?

“The depth depends on what the ground is like you have to dig to solid ground. For a single storey building strip foundations will typically be 450mm wide and at least 200mm deep, and for two storeys 600mm wide and 200mm deep.”

How much rebar do I need for footings?

Determine the amount of rebar needed for the footings. Generally, one stick of rebar per 8 inches of footing width will suffice. If your footings are 16 inches wide, you will need to add two sticks of rebar along the width of the footing; however, if your footings are 24 inches wide, you will need three sticks.

Which criteria is used for the calculation of depth of footing?

The depth and area of foundation is dependent on bearing capacity, depth of groundwater table, and depth of load bearing stratum.

Do I need rebar in footings?

Footings, that sit on undisturbed soil or sand or multiple combination of this and that natural material, don’t require rebar. Vertical walls and posts that do require rebar, the steel rods provide both remarkable lateral ductile strength while over many decades become the weakest link.

Article first time published on

Can you put too much rebar in concrete?

Using more than recommended will be uneconomical. Moreover, providing adequate spacing between the rebars will be difficult. IS 456:2000 recommends minimum and maximum spacing which has to be fulfilled. One more disadvantage of providing excess rebar is that the placement of concrete will become difficult.

How do you calculate steel isolated footing?

1. Length of Footing = X = 2m.
2. Breadth of Footing = Y = 1.6m.
3. Height of the footing (Thickness) = h =0.3m.
4. Diameter of the Main reinforcement bars = dm= 12mm.
5. Diameter of Distribution Reinforcement Bars = dd =12mm.
6. Spacing of Main reinforcement bars = sm = 150mm c/c.

What is the minimum depth of footing?

minimum depth of foundation:– minimum depth of foundation is around 5 feet for a small residential building from ground level or at least 1.50 times the width of footing. In cold climates the depth of footing is Kept at a minimum of 1.50m below surface because of possible frost action.

How long before you can build on concrete footings?

Follow-on work should be possible within 48 hours, although it is worth checking with your concrete supplier, and it is best to leave any formwork for 72 hours to avoid any possible damage to the edges of the concrete.

What is the freezing depth?

The frost line—also known as frost depth or freezing depth—is most commonly the depth to which the groundwater in soil is expected to freeze. The frost depth depends on the climatic conditions of an area, the heat transfer properties of the soil and adjacent materials, and on nearby heat sources.

What is strip footing?

A wall footing or strip footing is a continuous strip of concrete that serves to spread the weight of a load-bearing wall across an area of soil. It is the component of a shallow foundation.

How deep should a 2m foundation be?

Type of wallWall heightDepth of concreteSingle-skinUp to 1m300mmDouble-skinUp to 1m150mmDouble-skinOver 1m, up to 2m375-450mmRetaining wallUp to 1m150mm-300mm

Can you use breeze blocks as footings?

No. A concrete slab is reinforced with steel and anchored to the earth, which means it resists falling apart and moving across the surface. Concrete blocks will separate and move independently, which is bad for your house.

How deep is the foundation of a 2 storey house?

Footing depth for 2 storey (G+1) building:- for 2 storey (G+1) house or in simple 2 floor building, general thumb rule, using standard 9″ thick walls, we recommended to use depth of footing minimum 4′ (1.2m) beneath the ground level for isolated footing shallow foundation in gravel and sand soil with higher bearing …

How do I know if my foundation is shallow or deep?

Foundation which is placed near the surface of the earth or transfers the loads at shallow depth is called the shallow foundation. Foundation which is placed at a greater depth or transfers the loads to deep strata is called the deep foundation.

How deep should concrete foundations be?

Strip, trench fill or pad foundations must be cast at a minimum depth of 750mm in low plasticity clays, 900mm depth in medium, and British Standard 8004 recommends a minimum depth of 1m for foundations in the highest risk areas. If there are, or were, trees nearby, depths of up to 3m may be necessary.

How far apart should rebar be in concrete?

Place rebar in a grid pattern with a spacing between bars of approximately 12 inches. In either case, blocks should be used under the reinforcement to keep centered within the concrete.

Where should rebar be placed in a footing?

Placement of Rebars It is a general rule that reinforcements should be placed at the tension side at the bottom of the footing. In a square footing, rebars are placed uniformly in both directions. ACI code requires that the rebars be placed not more than 18 apart.

How close to the edge should rebar be?

Reinforcement should also be placed low enough so saw cutting does not cut the reinforcement. For welded wire reinforcement, the Wire Reinforcement Institute recommends steel placement 2 inches below the surface or within the upper third of the slab thickness, whichever is closer to the surface.

How long should a footing cure before laying block?

If you use a concrete that has a quick setting additive you need to wait a minimum of one sunny day, if you are using a standard concrete footing mix I would recommend waiting for a minimum of seven days and a maximum of 28 days, of course, that is if the conditions are right for the concrete to cure and set hard .

What happens if you don't put rebar in concrete?

Concrete is stellar as resisting compressive forces along the top skin, but without rebar to carry the tensile forces the bottom will fracture under a relatively small load and cause the slab to fail abruptly, like snapping a twig.

What is the standard footer size?

A concrete footer can be anywhere from 20 to 30 inches wide and 8 to 10 inches thick. You’ll see them 10-inches thick more often than not. The foundation wall is usually 8 inches wide.

Does 4 inch concrete need rebar?

Rebar is not necessary for every concrete project. The general rule of thumb is that if you are pouring concrete that is more than 5 inches in depth, you are probably going to want to add in some rebar to help reinforce the entire structure.

Is humidity good for curing concrete?

Moist Curing Concrete needs to remain moist in order for it to cure. Generally the internal relative humidity needs to be above 80% to 85% relative humidity for hydration to take place.

How do you calculate rebar spacing?

Find the rebar-to-spacing multiplier with the formula M = 0.9_sqrt(Pt), with “P” representing the percentage of steel required and “t” representing the thickness of the slab. For example, if the percentage is 0.65 and the thickness of the slab is 6 inches, M = 0.9_sqrt(0.65*6) = 1.78.

How do you calculate Bar Bending Schedule for footing?

1. Deduct the concrete cover to find the dimensions of bars.
2. Find the Length of single X Bars & Y Bars.
3. Find the total length of X bars. …
4. Calculate the weight of steel required per 1m.
5. Calculate the total number of 12m bars required.
