How do I unplug my Prodigy P2?

To remove the Tekonsha Prodigy P2 # 90885 you simply need to detach the harness at the rear of the brake controller. Once that is removed you can tuck the harness up under your dash with some zip ties andthe uninstall the bracket that holds the brake controller as well.

How do you unplug a trailer brake controller?

The easiest way to temporarily disconnect power to the trailer brakes is to disconnect your brake controller. Unplug the brake controller plug from the back of the brake controller. The trailer brakes cannot draw power from the vehicle’s battery if the brake controller is not plugged in.

How do you reset a prodigy brake controller?

The first step that we will want to take is to reset the brake controller. This is done by simply unplugging the brake controller for approximately 20 seconds and then reconnecting the brake controller.

Should I disconnect brake controller when not in use?

As long as you have a healthy battery, you should not have a problem. It you were to use a brake controller like a Tekonsha P2, part # 90885, you can disconnect the wiring at the back of the brake controller to make sure that none of the battery charge is consumed by the brake controller while off.

Does the Prodigy P2 turn off?

The display on the P2 will shut off automatically after 20-30 minutes of inactivity. The control will go into its sleep mode after 20-30 minutes of no brake pedal application or no manual lever activation.

How do you unplug a tekonsha brake controller?

You can detach the harness from the Tekonsha P3 brake controller by gently pulling up on the tab shown in the photo while pulling rearward on the connector. You’ll want to do this gently, so the tab doesn’t break.

Do electric brakes work in reverse?

Electric trailer brakes do work in reverse. When you engage the tow vehicle’s brake pedal, the brake controller will activate the electric trailer brakes regardless of whether you are driving forward or reversing.

Does the P3 brake controller stay on all the time?

Expert Reply: The P3 brake controller, # 90195, will go into a sort of sleep mode after it detects no movement for 15 minutes. While it is on it does not draw very much power. Corrosion in the vehicle/trailer side connectors could cause a short that would keep the brake controller on.

Will my brake controller drain my battery?

Brake Controller has Constant Power Output and is Draining the Battery on the Truck Brake controllers do send a little power back to check for a trailer but it should not be that much. You will either have an issue inside the brake controller or there is a short somewhere else that is causing a draw.

Is the Prodigy Brake Controller wired or wireless?

The Prodigy Wireless Brake Controller is a proportional brake controller from Tekonsha, one of the biggest manufacturers of towing accessories in the world. While they mostly offered wired brake controllers, they have recently started to offer a wireless option. With a wireless brake controller, you do not have to worry about wiring the system in.

How does the Tekonsha prodigy brake controller work?

The Tekonsha Prodigy uses a self-adjusting activation sensor and can be mounted in nearly any horizontal or vertical position. Other features of each brake controller, such as the boost function on the Prodigy, require separate troubleshooting steps.

How can I tell if my brake controller is working?

Check the display reading. If the display reads or flashes “P.L”, power to the controller is interrupted when the brake pedal is applied. Check the controller’s blue brake wire for proper connection and ensure the trailer’s brake signal wire is connected to the brake actuator magnets.
