How do I reset my Webasto diesel heater?

Heater Lock out Reset Procedure:

Using switch or standard timer control, turn heater on.
Remove the main power connection to heater from battery or pull fuse for a minimum of 20 seconds.
Using switch or standard timer control, turn the heater off.
Reinstall main heater power connection where previously disconnected.

Why is my diesel heater not working?

The most likely causes of heaters not starting is no fuel, insufficient power or no air flow. Please follow the steps below to check these issues. Remember to reset the heater between starting attempts by removing and replacing the fuse.

How much diesel does a Webasto heater use per hour?

How much fuel does a Webasto heater need per hour? Of course, the fuel consumption is strongly depending on the needed heating power and type of heater. As very rough and noncommittal proportion a heater needs 100 ml diesel per hour and kW. For further details, please see the heater’s technical specifications.

Which is better Eberspacher or Webasto?

Eberspacher is generally more expensive than the equivalent Webasto heater. Fuel Metering Pump: Webasto have introduced a new fuel quieter fuel pump so in this area they are now the same. Eberspacher heaters have 4 heat settings, with the Webasto having only 3 heat settings.

Who makes the best diesel heater?

Best Campervan Diesel Heaters [2020]

Best Overall Diesel Air Heater. Triclicks 5kW.
Best Budget Diesel Air Heater. maXpeedingrods 5kW.
Best Premium Diesel Air Heater. Webasto Air Top 2000 STC.
Best Alternate Diesel Air Heater Option. Triclicks All-In-One.

Can you mount diesel heater on its side?

Answer: It can be mounted on one side, but not the other otherwise the fuel may leak from the glow plug. You can tap into the fuel task on the vehicle or boat and it’s feed via a pump.

How long does a diesel heater last?

Not really. Normal usage of heaters is around 500 hours. Replacement parts after that time are usually the glow plug, filter and burner cartridge.

Do you need a muffler on a Webasto air heater?

Yes, but only if the fuel hasn’t been sourced correctly from the vehicle’s fuel tank. The recommendation is to cut the fuel standpipe so that it is 25mm from the bottom of the tank. 23.02

How does A Webasto diesel heater heat up?

Firstly the fan will run up to speed – this checks that the heater is not blocked or restricted in any way. Next the glow pin (or glow plug, if you prefer) heats up, if this all goes well, then the fuel metering pumps starts pumping.

Is there a separate fuel tank for Webasto?

Yes, Webasto can offer a separate 12L fuel tank for this application. The fuel tank is supplied with a quick connect coupling and sight glass. Question 8 –Are standard installation kits available? Based on our experience with manufacturers and aftermarket installers, we have developed comprehensive installation kits.

How much power does the Webasto at 2000 STC use?

Question 14 –How much power does the heater consume? The AT 2000 STC uses as little as 14 watts during normal operation (6-7 Amps at initial start phase, then 1-2 Amps during continuous running). Webasto Diesel Air Heaters FAQs – RV market Question 15 –What type of controllers are available for the heaters?

Can a camper run on a diesel heater?

If your camper runs on diesel, you’re never going to be short of fuel. The diesel heaters can run directly off your main tank so there’s no need for separate storage for different fuel types. Diesel is cheap, readily available and because they’re so efficient, the running costs of a diesel heater are insignificant.
