In general, you’ll want to use one hinge for every 30 inches of door height. For example: Use two hinges for doors up to 60 inches tall. Use three hinges if the door is between 60 and 90 inches tall.

How do I know what kind of hinges I need?

The construction of your cabinet – most notably, the overlay of the face frame and the cabinet door – determines which cabinet hinge you need. Similarly, where your drawer slides need to be mounted dictates what type of drawer slide you need.

What is a semi concealed hinge?

The term “semi-concealed” is applied when some of the hinge shows on the outside of the cabinet, but a portion of it is hidden behind the door.

What kind of hinge swings both ways?

Double-action, spring-loaded hinges allow doors to swing in both directions, as Hinge Outlet describes. You’ve probably seen them in restaurants or commercial buildings where traffic flows in both directions.

What are the different types of hinges?

• Ball Bearing Hinge. The ball bearing hinge has lubricated bearings between the hinge’s knuckles to reduce friction caused by heavy doors. …
• Spring-Loaded Butt Hinge. …
• Barrel Hinge. …
• Concealed Hinge. …
• Overlay Hinge. …
• Offset Hinge. …
• Piano Hinge. …
• Strap Hinge.

How do you measure cabinet inset hinges?

1. With the door closed, part of the thickness of the door fits inside the opening of the cabinet and is called the inset.
2. Inset is measured on the edge of the door. Possible inset dimensions include 3/8″, 1/2″, 5/8″ and 3/4″.

What is a 1/2 inch overlay hinge?

1/2″ overlay hinges are the most common overlay of cabinet hinge. These are used in face frame cabinets where the door covers a 1/2″ of the face frame all the way around the cabinet door. … These are used in face frame cabinets where the door covers a 1/2″ of the face frame all the way around the cabinet door.

Are all concealed hinges the same?

The type of concealed hinge you need depends on the application. There are many companies that make European-style hinges. Some well-known brands include Soss, Blum and Amerock. For entry or interior doors, the choice will be based on the size and thickness of the door and how many hinges you want to have.

How much larger should a cabinet door be than the opening?

Add space for door overlay: Cabinet doors for framed cabinets must be larger than the cabinet opening to look right and close properly. We refer to this as an “overlay”. The industry standard for most cabinet doors is a 1/2 inch overlay around the cabinet door.

What is a butler door?

What is A Butler Door? A “Butler Hinge” is also called a “Swinging Door Hinge,” and a “double action floor hinge.” It is a floor mounted hinge with spring tension that allows a door to swing in or out of a room and return to the closed position when let go.

Article first time published on

What is a double acting hinge?

Double action spring hinges allow a door to open 180 degrees in either direction. The spring action returns door to center closed position. These hinges are great for any door you want to walk through in both directions and have the door come back to center automatically.

How does a double acting hinge work?

A traditional door hinge has components like a capstan that allow it to rotate and allow a door to open and close. … Double-action hinges are made of two connected hinges, with one sitting outside the door frame on the left and the other connected to the door frame on the right.

What is a wrap around hinge?

Partial wrap hinges have an extra-long leaf that wraps around the edge of the cabinet face frame of side panel. … These specialty hinges can be surface-mounted on the door and the side panel of the cabinet or mortised into the door and the side panel.

What is a demountable hinge?

Single demountable hinges install with screws to the face of the cabinet frame, and the hinge slips into a slot on the edge of the door. Double demountable hinges have two slots – one in the face of the cabinet frame and one in the edge of the door.

Can I use concealed hinges on partial inset doors?

Concealed hinges can go in face-frame or frameless cabinets and on any door type—including full overlay, partial overlay, or inset—as long as the doors are at least ½ inch thick.

Should a door have 2 or 3 hinges?

The general rule used to determine the number of hinges is: Every door should be provided with at least one hinge for every 30 inches in height or portion thereof; however, more hinges may be required per chart below. For example, a 90″ door needs three hinges and a 91″ door needs four.

What kind of hinge opens 180 degrees?

Wide throw hinges are used when you need extra clearance behind a door – typically a door that opens 180 degrees.

What are the 4 styles of hinge called?

• Corner hinges. These are typically used on metal cabinets and machine covers and sit flush to the surface. …
• Lift-off hinges. …
• Offset hinges. …
• Piano hinges. …
• Leaf hinges. …
• Concealed hinges. …
• Side hinges. …
• Weld-on hinges.

How do you measure double demountable hinges?

Finding the precise dimensions is simple and straightforward. Start by closing the cabinet door and lining up the edge of the door with the edge of a piece of tape. Apply the tape to the face frame of the cabinet on the hinged side. Open the cabinet door and measure from the inside edge of the tape near the opening.

What is the difference between inset and overlay hinges?

Inset Cabinet Doors are set into the cabinet frame and fit flush with the face of the cabinet when closed. … Full Overlay Doors give a similar appearance to that of inset doors without the higher cost. They completely cover the cabinet face, providing the flat cabinet front so desired in inset cabinets.

What are standard kitchen door sizes?

The most common standard kitchen door size is 60cm. However, widths of 30cm, 40cm, 80cm and 100cm are also considered standard sized carcasses. Generally, 60cm kitchen units are fitted with one door, while the larger sizes often have two. These are important things to consider when designing your kitchen.

How do I measure for cabinet doors?

1. Remove the door you want to measure.
2. Measure the opening from top to bottom, and then left to right, then write down the exact width and the exact height of the opening.
3. Then add in your overlay.

What are standard cabinet sizes?

• Upper kitchen cabinets are 12, 15, 18, 24, 27, 30, 33, and 36 inches.
• Upper filler cabinets are 3, 6, and 9 inches wide.
• Standard base cabinet widths are 12, 15, 18, 21, 24, 26.25, 27, 30, 33, 26, 39 and 42-inches.

Which side of the hinge goes on the door?

Mark the Hinge Placement on the Door Use the tape measure to mark the on-center placement points for the hinges. Lay a hinge down on the mark. The pin side should be on the side of the door swing. The hinge must step back from the edge of the door.

How many hinges should a door have?

Hinge Size As a rule, use one hinge per every 30 inches of door: Doors up to 60 inches need two hinges. Doors over 60 inches, but not over 90 inches, need three hinges. Doors over 90 inches, but not over 120 inches, need four hinges.

What is face frame hinge?

Face Frame cabinets – Face-frame cabinets incorporate a frame (often made from 1-1/2″ to 2″ wide solid wood) that is attached to the front edges, or face, of the case. Hinges mount to this face frame. This is the most common style in American cabinets.

How many hinges are needed for a cabinet door?

The number of hinges you need depends on the height and weight of the door. Use two hinges for doors less than 40 inches high and less than 11 pounds. Use three hinges for doors 40 to 60 inches high and 13 to 20 pounds. Use four hinges for doors 60 to 80 inches high and 29 to 33 pounds.

Are door hinge holes standard?

Hinge holes are drilled at a 35mm diameter, and 12.5mm deep. All hinge holes are drilled to an industry standard: 22mm from the edge of the door to the centre of the hole.

Are kitchen door hinges standard?

This is a typical concealed hinge used on Kitchen, Bedroom Bathroom and built in cupboards. They come in two sizes 35mm dia and 26mm dia hole size. Most hinges used are the 35mm dia. 26mm dia hinges are sometimes used in small bathroom cabinets or budget carcasses.
